Magnetic Properties of AlNiCo Magnets
BUILD YOUR CUSTOM MAGNETSSee what tcm magnetics can do for you
Request a quote today
| Grade | MMPA Equivalent | Br | Hcb | Hcj | (BH)max | Remark | ||||
| mT | Gs | kA/m | Oe | kA/m | Oe | kJ/m3 | MGOe | |||
| LN10 | Alnico3 | 600 | 6000 | 40 | 500 | 43 | 540 | 10 | 1.20 | Isotropic |
| LNG13 | Alnico2 | 680 | 6800 | 48 | 600 | 51 | 640 | 13 | 1.60 | |
| LNGT18 | Alnico8 | 580 | 5800 | 90 | 1130 | 92 | 1160 | 18 | 2.20 | |
| LNG37 | Alnico5 | 1200 | 12000 | 48 | 600 | 49 | 610 | 37 | 4.65 | Anisotropic |
| LNG40 | 1250 | 12500 | 48 | 600 | 49 | 610 | 40 | 5.00 | ||
| LNG44 | 1250 | 12500 | 52 | 650 | 53 | 660 | 44 | 5.50 | ||
| LNG52 | Alnico5DG | 1300 | 13000 | 56 | 700 | 57 | 710 | 52 | 6.50 | |
| LNG60 | Alnico5-7 | 1350 | 13500 | 59 | 740 | 60 | 750 | 60 | 7.50 | |
| LNGT28 | Alnico6 | 1000 | 10000 | 58 | 720 | 59 | 740 | 28 | 3.50 | |
| LNGT36J | Alnico8HC | 700 | 7000 | 140 | 1750 | 148 | 1850 | 36 | 4.50 | |
| LNGT38 | Alnico8 | 800 | 8000 | 110 | 1380 | 112 | 1400 | 38 | 4.75 | |
| LNGT44 | 880 | 8800 | 120 | 1500 | 122 | 1530 | 44 | 5.50 | ||
| LNGT60 | Alnico9 | 900 | 9000 | 110 | 1380 | 112 | 1400 | 60 | 7.50 | |
| LNGT72 | 1050 | 10500 | 112 | 1400 | 114 | 1430 | 72 | 9.00 | ||
AlNiCo Magnets - Physical Properties
| Curie Temperature (°C) | 860 |
| Maximum Operating Temperature (°C) | 525-550 |
| Resistivity (µ ohm.cm) | 47-54 |
| Hardness (Hv) | 520-630 |
| Density (g/cm3) | 6.90-7.30 |
| Relative Recoil Permeability (µrec) | 1.70-4.70 |
| Saturation Field Strength, kOe (kA/m) | 2.7-6.3 (215-500) |
| Temperature Coefficient of Br (%/°C) | -0.025 ~ -0.02 |
| Temperature Coefficient of iHc (%/°C) | +0.01 ~ +0.03 |
